08/2005 Expanding the Operator Interface (BE1)
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/5-127
5.2 Selection displays created with "Expand user interface"
An Action value >= 100 automatically switches the HMI software to Expand user
interface operational sequences.
If Action >= 100, the configuration of the INI files determines which softkey menu
or screen form should be displayed and in which state.
5.2.1 INI files and sections
HMI Advanced and HMI Embedded
The following INI files and sections can be configured for the jump entry to Expand
user interface:
Operating area
| File | Section
Machine:
machine.ini
[KeyConfigurationAuto]
[KeyConfigurationMDA]
[KeyConfigurationJOG]
Parameter:
paramet.ini
[KeyConfiguration]
Programming:
program.ini
[KeyConfiguration]
Services:
services.ini
[KeyConfiguration]
Diagnostics:
diagnosis.ini
[KeyConfiguration]
Start-up:
startup.ini
[KeyConfiguration]
Custom:
custom.ini
[KeyConfiguration]
JobShop
The INI files for the JobShop products ShopMill and ShopTurn are called
shopmill.ini and shopturn.ini.
Both files contain the following sections, in which Expand user interface functions
can be configured as described in 5.2.2 Configuring.
[MachineManual]
...
[MachineAutomatic]
...
[ProgramManager]
