Because there can be several versions (e.g., NC1, NC2, etc.) for such a cycle, an
additional section must be furnished in the INI file for this entry [CYC82].
Section for cycles (e.g.: [CYC82])
No.
Number of cycle versions.
NCG_1_Label
“Name” of version. Generally, this is the text that is found in the NC program after
the path of the COM file (NC1, NC2, etc.).
NCG_1_Text
Text that is displayed. A fixed text, a language-specific text ($85111), or a
combination of both ($85111/my additional text) can be specified.
NCG_1_Ico
Associated icon, it must be located in the directory that was specified in IconPath.
NCG_1_Level
Definition of whether cycle is to be displayed as a subblock or a main block.
1: Subblock
0: Main block
Note
See also: /IAM/ BE1 Expand User Interface
2.5.23 SIMTOGEO.INI
Sample file with the details required for simulation for the individual tool types.
Note
If Link is set to 0 in the [Settings] section, the other entries in SIMTOGEO.INI
have not effect.
[Settings]
; this entry is dependent on settings such as
;
; MD 18206: $MN_MM_NUM_CCS_TOA_PARAM=1
; MD 18207: $MN_MM_TYPE_CCS_TOA_PARAM[1]=4
; MD 18080: $MN_MM_TOOL_MANAGEMENT_MASK='H4'
;
; if required and / or if other oem parameters are used, the index can be changed
; ( e.g. TC_DPCS4 if $MN_MM_NUM_CCS_TOA_PARAM=4 )
; or any other oem variable than TC_DPCS1 can be used :
