Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-148 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
Example 8: Screen 2
ANW.VAR TEST_1
O
ANW.VAR TEST_1
ANW.VAR TEST_1
5.00000
2.7.10 List of Files for the Dialog Screens
Part programs
%_N_MMC_EXAMPLE1_MPF
N10 MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN1,GUD4.DEF,,,A1","N")
N20 TEST_1 = 1
N25 G4 F10
N30 MMC("CYCLES,PICTURE_OFF","N")
M30
%_N_MMC_EXAMPLE2_MPF
N10 MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN6,GUD4.DEF,,10,
T1,G1","N")
N15 G4 F15
N20 MMC("CYCLES,PICTURE_OFF","N")
M30
%_N_MMC_EXAMPLE3_MPF
N15 MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN1,GUD4.DEF,,,F1","S")
N20 TEST_1 = 5
N30 MMC("CYCLES,PICTURE_OFF","N")
M30
%_N_MMC_EXAMPLE4_MPF
N15 MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN2,GUD4.DEF,,,C1","S")
N20 TEST_3 = 5
N30 MMC("CYCLES,PICTURE_OFF","N")
M30
