08/2005 Expanding the Operator Interface (BE1)
2 First Steps
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/2-17
2.2.2 Saving the configuration file
Configuration files are saved for
HMI Advanced in the DH directory
HMI Embedded in the user cycles directory
2.2.3 Function
Pressing the start softkey loads the assigned screen form. This will also activate
the softkeys associated with the screen form. Variables will be output to the
standard positions unless specific positions have been configured.
Note
Chapter 3 contains detailed information about the structure of the configuration
file.
