Siemens SINUMERIK 810D Commissioning Manual

08/2005 Starting Up HMI Embedded (IM2)
9 Configure Windows in the NC Program
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/9-133
9.8 Example program 8: Asynchronous acknowledgment mode
with softkeys
Softkeys can be preprogrammed in the COM file for display in asynchronous mode,
linked with the acknowledgment variable and evaluated in the parts program.
Parts program
N10 QUIT_1 = "START"
N20 MMC("CYCLES, PICTURE_ON,T_SK.COM,SCREEN3,GUD4.DEF,,
QUIT_1,K1","A")
N30 LABEL0:
N40 STOPRE
N50 IF MATCH (QUIT_1,"SK1") >= 0 GOTOF LABEL1
N60 IF MATCH (QUIT_1,"SK2") >= 0 GOTOF LABEL2
N70 GOTOB LABEL0
N80 LABEL2:
N90 MMC("CYCLES, PICTURE_ON,T_SK.COM,SCREEN1,GUD4.DEF,,,
N1","N")
N100 G4F10
N110 LABEL1:
N120 MMC("CYCLES, PICTURE_OFF","N")
N130 M30
Dialog screen file
(*.COM)
//C3(Screen3)
(S/// USER VAR QUIT_1/W/QUIT_1//)
[TEXT VARIABLES]
K1 = ..Example8: MMC command with asynchronous acknowledgment mode
N1 = ..Example8: Screen2
Text variable
[SCREEN3]
SK1 = END
SK2 = Screen2
Example 8: MMC command with asynchronous acknowledgement mode
OK
A
NW.VAR TEST_1 START
END Screen2
Softkey 8
Softkey 14
Softkey 13
Softkey 12
Softkey 11
Softkey 10
Softkey 9
Softkey 15
Softkey 0
Softkey 7 Softkey 6
Softkey 5 Softkey 4
Softkey 3 Softkey 2
Softkey 1
