08/2005 Expanding the Operator Interface (BE1)
3 Syntax
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/3-49
Note
The display colors might appear differently on HMI Embedded/HT6 than in
PaintShopPro. For more information about handling (e.g., search methods in
general and search sequence for displays), see Subsection 7.4.3, Chapter 8
"Color table".
Display building, HMI Advanced
Graphics/display images and Help displays can have the following format:
Bitmap (BMP)
Metafile (WMF) or
Icon (ICO)
Graphic programs can be freely selected provided that they are capable of
generating the prescribed formats.
Displays must be saved in one of the following directories:
\DH\CUS.DIR\HLP.DIR (User cycles directory)
\DH\COM.DIR\HLP.DIR (Comments directory)
\DH\CST.DIR\HLP.DIR (Standard cycles directory)
\DH\CMA.DIR\HLP.DIR (Manufacturer directory)
3.3.11 Display within a display
You can insert further displays in the background (Help display). Even as a function
of the values of the variables.
Like for softkeys you can assign a graphics file to a display field. The height of the
displayed graphic (of the I/O field) is specified as the fourth parameter of the
positions.
You can define bitmaps in fields (short text, I/O field).
The definition is made with the notation used in "Defining variables" (see
Subsection 3.3.3 “Screen form elements”).
Example:
Short text field
is overlaid with graphics
DEF VAR1=(S///,"\\image1.bmp" ////160,40,50,50) ; Type S irrelevant
Toggle field
overlaid with graphics, the graphic being selected with a PLC flag byte.
DEF VAR1=(IDB/*1="\\image1.bmp", 2="\\image2.bmp"//,"$85000"/wr1//
"MB[0]"//160,40,50,50)
