Siemens SINUMERIK 810D Commissioning Manual

08/2005 Expanding the Operator Interface (BE1)
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/5-139
5.8 List of selectable states ShopTurn
*) These designated functions can be configured with the Expand user interface
system. If this type of configuration is available, it is activated. Otherwise, the
standard ShopTurn screen will appear.
5.8.1 Machine Manual
State Function Remark
19 Manual basic screen
2 T,S,M,...
21 Set basic ZO
30 Workpiece zero
31 *)
34 *)
35 *)
36 *)
37 *)
38 *)
40 *)
50 Measuring tool
51 Length manual X *)
52 Length manual Z *)
53 Tool gauging with zoom-
in function
*)
54 *)
55 *)
56 Probe calibration *)
57 *)
58 Automatic tool gauging X
59 Automatic tool gauging Z
20 MDA
4 Position
80 Stock removal After "acceptance" 81; output
only, screen cannot be
accessed
90 *)
After "acceptance" 91; output
only, screen cannot be
accessed
1 Settings
