Siemens SINUMERIK 810D

Expanding the Operator Interface (BE1) 08/2005
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
BE1/5-140 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.8.2 Machine Auto
State Function Remark
200 Current block display
210 Program control
220 Block search
230 *)
Simultaneous recording:
242 3-window view
243 Side view
244 Front view
245 Volume model
5.8.3 Program Manager
State Function
300 NC directory
310 User path
320 User path
330 User path
340 User path
5.8.4 Program
State Function
400 Program listing
Simulation:
412 3-window view
413 Side view
414 Front view
415 Volume model
5.8.5 Messages/alarms
State Function Remark
500 Messages
510 *)
520 *)
