08/2005 Commissioning HMI Advanced (IM4)
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
IM4/2-139
2.7.3 Example 1: MMC Command without Acknowledgment
Part program
N10
MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN1,GUD4.DEF,,,A1","N")
N20 TEST_1 = 1
N25 G4 F10
N30 MMC ("CYCLES, PICTURE_OFF", "N")
M30
Dialog screen file (*.COM)
//C1(SCREEN1)
(R///USER VAR TEST_1/W/TEST_1///)
Text variable
TEXT VARIABLES]
A1 =............Example1: MMC command without acknowledgment………
Sequence
The user variable TEST_1 from GUD4.DEF with header A1 is displayed for a short
time.
The dwell time comes from part program block N25.
Example 1: MMC command without acknowlg
USER VAR TEST_1
1.000000
