08/2005 Online Help (HE1)
2 Alarm/Machine Data Help
© Siemens AG, 2005. All rights reserved
SINUMERIK 840 sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
HE1/2-35
Layout of the text file
Pdf file without language
code
MD No. Page
DROT.PDF 1000 1
DROT.PDF 1001 1
DROT.PDF 1002 1
... ... ...
Explanation of names
Name Significance
N_NCK_GR.PDF General MDs
C_NCK_GR.PDF Channel-specific MDs
A_NCK_GR.PDF Axis-specific MDs
S_NCK_GR.PDF Setting Data
DISPL_GR.PDF Display MDs
DROT_GR.PDF Drive MDs, rotary
DLIN_GR.PDF Drive MDs, linear
HYDRM_GR.PDF Drive MDs, hydraulics module
2.3.2 Expanding the Machine Data Help
If additional user machine data are to be displayed in the MD Help, these must be
added in the form of a pdf file and in a txt file of the same name in the
C:\USER\HLP directory.
Required files
• *.pdf e.g. n_nck_gr.pdf
• *.txt e.g. n_nck_gr.txt
1
Define
jump labels in the document
The jump labels must be marked with an index entry in the document (e.g.
WinWord) to be displayed at the control as pdf and a single-column index list (page
numbers right-justified) produced.
2
Create text file
Copy the single-column index created above (page number right-justified) and save
it as a txt file.
Example: 10000 170
