08/2005 Expanding the Operator Interface (BE1)
7 Configuring and Working Environment
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/7-165
Overview
PRJ1 PRJ2 PRJ3
Configured screen form files Control file
MMC 100.2, HMI, HT6
Programming
Editor
PCMCIA CARD
NC
PC or PG
PCMCIA CARD
System environment
Application environment
PCIN/SinuCom PCIN
Sinucopy FFS
PCMCIA CARD
replugging for
booting
Common.
com
Fig. 7-1 Procedure for generating a PCMCIA card with screen form configuration files
