08/2005 Expanding the Operator Interface (BE1)
8 Terms, Tables, Lists, Examples
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/8-191
Name Index Description
$SC_PA_CONT_ABS
[x,7]
x=Number
protection zone
Abscissa of end point of 8
th
contour element
$SC_PA_CONT_ABS
[x,8]
x=Number
protection zone
Abscissa of end point of 9
th
contour element
$SC_PA_CONT_ABS
[x,9]
x=Number
protection zone
Abscissa of end point of 10
th
contour element
$SC_PA_CONT_
NUM[x]
x=Number
protection zone
Number of valid contour elements
$SC_PA_CONT_
ORD[x,0]
x=Number
protection zone
Ordinate of end point of 1st contour element
$SC_PA_CONT_
ORD[x,1]
x=Number
protection zone
Ordinate of end point of 2nd contour element
$SC_PA_CONT_
ORD[x,2]
x=Number
protection zone
Ordinate of end point of 3rd contour element
$SC_PA_CONT_
ORD[x,3]
x=Number
protection zone
Ordinate of end point of 4th contour element
$SC_PA_CONT_
ORD[x,4]
x=Number
protection zone
Ordinate of end point of 5th contour element
$SC_PA_CONT_
ORD[x,5]
x=Number
protection zone
Ordinate of end point of 6
th
contour element
$SC_PA_CONT_
ORD[x,6]
x=Number
protection zone
Ordinate of end point of 7
th
contour element
$SC_PA_CONT_
ORD[x,7]
x=Number
protection zone
Ordinate of end point of 8
th
contour element
$SC_PA_CONT_
ORD[x,8]
x=Number
protection zone
Ordinate of end point of 9
th
contour element
$SC_PA_CONT_
ORD[x,9]
x=Number
protection zone
Ordinate of end point of 10
th
contour element
$SC_PA_CONT_TYP
[x,0]
x=Number
protection zone
Contour type of 1st contour element
$SC_PA_CONT_TYP
[x,1]
x=Number
protection zone
Contour type of 2nd contour element
$SC_PA_CONT_TYP
[x,2]
x=Number
protection zone
Contour type of 3rd contour element
$SC_PA_CONT_TYP
[x,3]
x=Number
protection zone
Contour type of 4th contour element
$SC_PA_CONT_TYP
[x,4]
x=Number
protection zone
Contour type of 5th contour element
$SC_PA_CONT_TYP
[x,5]
x=Number
protection zone
Contour type of 6
th
contour element
$SC_PA_CONT_TYP
[x,6]
x=Number
protection zone
Contour type of 7
th
contour element
$SC_PA_CONT_TYP
[x,7]
x=Number
protection zone
Contour type of 8
th
contour element
$SC_PA_CONT_TYP
[x,8]
x=Number
protection zone
Contour type of 9
th
contour element
$SC_PA_CONT_TYP
[x,9]
x=Number
protection zone
Contour type of 10
th
contour element
$SC_PA_LIM_3DIM
[x]
x=Number
protection zone
Limitation of protection zone applicate
$SC_PA_MINUS_LIM
[x]
x=Number
protection zone
Lower limit of protection zone, applicate
