8 Terms, Tables, Lists, Examples
© Siemens AG, 2005. All rights reserved
BE1/8-194 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Name Index Description
$SN_PA_CONT_TYP
[x,7]
x=Number
protection zone
Contour type of 8
th
contour element
$SN_PA_CONT_TYP
[x,8]
x=Number
protection zone
Contour type of 9
th
contour element
$SN_PA_CONT_TYP
[x,9]
x=Number
protection zone
Contour type of 10
th
contour element
$SN_PA_LIM_3DIM
[x]
x=Number
protection zone
Limitation of protection zone applicate
$SN_PA_MINUS_LIM
[x]
x=Number
protection zone
Lower limit of protection zone, applicate
$SN_PA_ORI[x] x=Number
protection zone
Plane assignment of protection zone
$SN_PA_PLUS_LIM
[x]
x=Number
protection zone
Upper limit of protection zone, applicate
$SN_PA_T_W[x] x=Number
protection zone
Workpiece or tool-related protection zone
$TC_ADPT... Adapter data
$TC_ADPTx;
$TC_ADPTT
x=1, ... 3, Number of parameters per adapter
$TC_DPCE Transformed edge correction value
$TC_DPCE Edge correction value
$TC_DPCx[y,z] x=ParamNo,y=Tool
No z=EdgeNo
User-defined tool edge parameter
$TC_DPx[y,z] x=ParamNo
y=ToolNo
z=EdgeNo
Edge correction value
$TC_DPx[y,z]
x=ParamNo
y=ToolNo
z=EdgeNo
Transformed edge correction value
$TC_ECP... Transformed location-dependent setup correction
$TC_MAMP3 Wear compound strategy
$TC_MAP1 Type of magazine
$TC_MAP2 Identifier of the magazine
$TC_MAP3 Status of magazine
$TC_MAP4 Link 1 between magazine and next magazine
$TC_MAP5 Link 2 between magazine and preceding magazine
$TC_MAP6 Magazine dimension
$TC_MAP9 Number of active wear group
$TC_MAPCx[y] x=ParameterNo
y=MagazineNo
Magazine user data for a tool magazine
$TC_MOP1(x,y) ...$TC
_MOP15(x,y)
x=ToolNo
y=EdgeNo
Monitoring data for each tool edge
$TC_MOP1(x,y) ...$TC
_MOP15(x,y)
x=ToolNo
y=EdgeNo
Monitoring data for each tool edge
$TC_MOPCx[y,z] x=ParamNo,
y=T-Number,
z=Edge
Monitoring user data for a tool edge
$TC_MPPCx[y,z] x=ParamNo
y=MagazineNo
z=MagPlaceNo
Magazine location user data for a tool magazine
$TC_MPPx x=1,...7 No. of parameters per magazine location
$TC_SCP... Transformed position-dependent wear correction
