Starting Up HMI Embedded (IM2) 08/2005
2 Power On and Ramp-Up
© Siemens AG, 2005. All rights reserved
IM2/2-14 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
2.1 Ramp-up
You need to insert the CompactFlash Card containing the HMI Embedded software
into the slot marked "CF" (interface X109) before
switching on the NCU.
Once the power supply is switched on, the NCU ramps up automatically and
detects the CompactFlash card.
An 8-digit HMI Embedded version number is displayed during ramp-up. The
seconds-counter display can be used to monitor when the connection to the
NCK/PLC has been established.
Further information about the ramp-up is contained in the submanual of the CNC
Installation and Startup Manual Part 5 (Base Software):
References: IAM2/IM5: Installation and Startup TCU, Section:
Operation during ramp-up.
