Siemens SINUMERIK 810D Commissioning Manual

Starting Up HMI Embedded (IM2) 08/2005
3 Communication/Initial Requirements
© Siemens AG, 2005. All rights reserved
IM2/3-28 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
3.4 "Blue screen" error status screen
If the system crashes, an error status screen ("Blue Screen") showing current
system information is displayed.
The error status screen displays a brief description of the error, which has
occurred, plus all relevant processor registers.
Backup option
A complete system data image is transferred to the CompactFlash card (optional).
System data display
In the event of a system crash, the crash address, the register allocation and any
additional information needed for crash analysis are displayed on the screen.
When you select key:
"S" (Save) you open the menu for saving data,
"R" to restart the NCU.
Sorry, but HMI Embedded has caused an exception in task XXXXX
Function at XXXXXXXX with code XXXXX
The type of exception is: XXXXXXXXXXXXXXXXXXXXX
The exception has occurred at cs: XX eip : XXXXXXXX!
EAX= XXXXXXXX EBX= XXXXXXXX ECX= XXXXXXXX EDX= XXXXXXXX
EDI= XXXXXXXX ESI= XXXXXXXX FLAGS= XXXXXXXX DS= XXXX ES= XXXX
SS= XXXX ESP= XXXXXXXX EBP= XXXXXXXX FS= XXXX GS= XXXX
Additional information:
XXXXXXXX loaded at: XXXXXXXX XXXXXXXX loaded at: XXXXXXXX
XXXXXXXX loaded at: XXXXXXXX XXXXXXXX loaded at: XXXXXXXX
...
XXXXXXXX loaded at: XXXXXXXX XXXXXXXX loaded at: XXXXXXXX
CODE = XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
EIP: XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
STACK= XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX
XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX
XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX
XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX
Please send the above or saved information to the SINUMERIK Hotline!
email: ad.support@siemens.com
Fill in subject: "HMI-Embedded exception (SW XX.XX.XX; date)"
Press 'S' to save data or press 'R' to reboot immediately
