Siemens SINUMERIK 810D - Page 334

Starting Up HMI Embedded (IM2) 08/2005
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM2/4-84 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
9310 V24_PRINTER_XON
H05
CR: C4
- Printer: X on character REAL 3/4
OP30, Emb OP30: 17, Emb:
17
0 0xFF
IMMEDIATE
LY
-
9311 V24_PRINTER_XOFF
H05
CR: C4
- Printer: X off character REAL 3/4
OP30, Emb OP30: 19, Emb:
19
0 0xFF
IMMEDIATE
LY
-
9312 V24_PRINTER_EOF
H05
CR: C4
- Printer: End of transmission character REAL 3/4
OP30, Emb OP30: 12, Emb:
12
0 0xFF
IMMEDIATE
LY
-
9313 V24_PRINTER_CONTROLS
H05
CR: C4
- Printer: Special bits REAL 3/4
OP30, Emb OP30: 76, Emb:
76
0 0x3FF
IMMEDIATE
LY
-
9314 V24_PRINTER_RTS
H05
CR: C4
- Printer: Line-controlled BYTE 3/4
OP30, Emb OP30: 0, Emb: 0
0 1
IMMEDIATE
LY
-
9315 V24_PRINTER_BAUD
H05
CR: C4
- Printer: Baud rate (
300, 600, 1200, 2400, 4800, 9600, 19200)
0 1 ...
BYTE 3/4
OP30, Emb OP30: 5, Emb: 5
0 8
IMMEDIATE
LY
-
9316 V24_PRINTER_DATABITS
H05
CR: C4
- Printer: Data bits BYTE 3/4
OP30, Emb OP30: 1, Emb: 1
0 1
IMMEDIATE
LY
-
9317 V24_PRINTER_PARITY
H05
CR: C4
- Printer: Parity bits BYTE 3/4
OP30, Emb OP30: 0, Emb: 0
0 2
IMMEDIATE
LY
-
9318 V24_PRINTER_STOPBIT
H05
CR: C4
- Printer: Stop bits BYTE 3/4
OP30, Emb OP30: 0, Emb: 0
0 1
IMMEDIATE
LY
-
9319 V24_PRINTER_LINE
H05
CR: C4
- Printer: RS-232-C interface (COM1/COM2)
(COM1/COM2)
BYTE 3/4
Emb Emb: 1
1 2
IMMEDIATE
LY
-
9320 V24_PG_PC_XON
H05
CR: C4
- PG: X on character
9321 PG: X off character
REAL 3/4
OP30, Emb OP30: 17, Emb:
17
0 0xFF
IMMEDIATE
LY
-
9321 V24_PG_PC_XOFF
H05
CR: C4
- REAL 3/4
OP30, Emb OP30: 19, Emb:
19
0 0xFF
IMMEDIATE
LY
-
