Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-104 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
Note
The NC writes the channel number of the HMI in DB19, DBB22.
The example below is simplified for 1:1 assignment of HMI : NCU
such that conn_2 is omitted and all channels are located on NCU_1.
Example:
NETNAMES.INI
[own]
owner = MMC_1
; Description of possible connections
[conn MMC_1]
conn_1 = NCU_1
conn_2 = NCU_2
; Description of significant net parameters
[param network]
bus = opi ; the MPI interface must be used on the SINUMERIK 810D
[param MMC_1]
mmc_address = 1
[param NCU_1]
nck_address = 12
plc_address = 12
; core name for the PLC symbol files for representing signals with symbols
PlcSymbolFile= ...
[param NCU_2]
nck_address = 14
plc_address = 14
; core name for the PLC symbol files for representing signals with symbols
PlcSymbolFile= ...
[chan MMC_1]
DEFAULT_logChanGrp = Milling1
DEFAULT_logChan = Channel13
ShowChanMenu = TRUE
logChanSetList = Milling1, Milling2
[Milling1]
logChanList = Channel11, Channel12, Channel13, Channel14, Channel15
[Channel11] ; logical channel
logNCName = NCU_1 ; logical NCU name see above
ChanNum = 1 ; channel number within NCU
[Channel12]
logNCName = NCU_1
ChanNum = 2
[Channel13]
logNCName = NCU_1
ChanNum = 3
[Channel14]
logNCName = NCU_1
ChanNum = 4
