Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-126 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
The associated values in SimToGeo.ini then appear below the corresponding
identifier, e.g.
Example: [500.1] ; Roughing tool 1
tool_type = 500
...
Optional parameters for orienting milling cutters:
TC_DPV3= ; 1 = +X, -1 = -X
TC_DPV4= ; 1 = +Y, -1 = -Y
TC_DPV5= ; 1 = +Z, -1 = -Z
Only one of these entries may be used. A free tool orientation cannot be entered.
Note
- Tools are still displayed in the 3 main planes, XY, YZ or ZX.
- If a tool cannot be displayed, a polymarker is displayed.
- With the SimToGeo.ini file the tool_type can be defined differently from the
NC settings. If the corresponding cutting edge parameters (e.g.
$TC_DPCS1[t,d]) can be set, a link to/evaluation by SIMTOGEO.INI geometrical
data is also possible.
- A complete sample file with entries for each permissible tool type can be found
in Subsection 5.6.10.
Machine data settings
MD 18206: MM_NUM_CCS_TOA_PARAM=1
; Number of OEM data per cutting edge 0 to 10
MD 18204: MM_TYPE_CCS_TOA_PARAM[0]=4
; Data type 4 = Real
MD 18080: MM_TOOL_MANAGEMENT_MASK='H4'
; Set aside memory for OEM data
Startup procedure
1. Activate the "Flying edge" function in DPTWP.INI or DPMWP.INI, for lathes or
milling respectively, [Setup] section:
[SETUP]
;*** only SW6.4 or later ***
;Display tool only as cutting edge-"flying edge" (on/off)
TOOL_AS_CUTTING_EDGE=ON ; default = OFF
2. Define machine data or memory for OEM parameters:
$MN_MM_TOOL_MANAGEMENT_MASK=4 ; For SimToGeo.ini
; Set bit 2=1
If MD have already been assigned, the bit must also be set
