Page #31 background image
Addr. Parameter Setting Options Default Setting Comments
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
190 RTD-BOX INPUT Disabled
Port C
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
- FLEXIBLE FCT. 1...20 Flexible Function 01
Flexible Function 02
Flexible Function 03
Flexible Function 04
Flexible Function 05
Flexible Function 06
Flexible Function 07
Flexible Function 08
Flexible Function 09
Flexible Function 10
Flexible Function 11
Flexible Function 12
Flexible Function 13
Flexible Function 14
Flexible Function 15
Flexible Function 16
Flexible Function 17
Flexible Function 18
Flexible Function 19
Flexible Function 20
Please select Flexible Functions 1...20
Device, General Settings
The device requires some general information. This may be, for example, the type of annunciation to be
issued in the event of an occurrence of a power system fault.
Command-dependent Messages
Spontaneous Fault Indications
After a fault, the most important fault data are spontaneously displayed on the device. Address 610
FltDisp.LED/LCD allows to select whether the spontaneous fault indications will be updated on every fault
(Target on PU) or only in the case of faults involving a trip (Target on TRIP).
2.1.2
2.1.2.1
Functions
2.1 General
SIPROTEC 4, 7SJ61, Manual 31
C53000-G1140-C210-6, Edition 05.2016
