Addr. Parameter Setting Options Default Setting Comments
7240 bef.4.Cy:51 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 51
7241 bef.4.Cy:51N Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 51N
7248 bef.1.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-3
7249 bef.1.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-3
7250 bef.2.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50-3
7251 bef.2.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50N-3
7252 bef.3.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50-3
7253 bef.3.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50N-3
7254 bef.4.Cy:50-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50-3
7255 bef.4.Cy:50N-3 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-3
Information List
No.
Information Type of
Informa-
tion
Comments
127 79 ON/OFF IntSP 79 ON/OFF (via system port)
2701 >79 ON SP >79 ON
2702 >79 OFF SP >79 OFF
2703 >BLOCK 79 SP >BLOCK 79
2711 >79 Start SP >79 External start of internal A/R
2715 >Start 79 Gnd SP >Start 79 Ground program
2716 >Start 79 Ph SP >Start 79 Phase program
2722 >ZSC ON SP >Switch zone sequence coordination ON
2723 >ZSC OFF SP >Switch zone sequence coordination OFF
2730 >CB Ready SP >Circuit breaker READY for reclosing
2731 >Sync.release SP >79: Sync. release from ext. sync.-check
2753 79 DT delay ex. OUT 79: Max. Dead Time Start Delay expired
2.11.8
Functions
2.11 Automatic Reclosing System 79
SIPROTEC 4, 7SJ61, Manual 165
C53000-G1140-C210-6, Edition 05.2016
