7SJ61 Approx. 3 VA Approx. 7 VA
Bridging Time for Failure/Short-Circuit
(in not energized operation)
200 ms
Binary Inputs and Outputs
Binary Inputs
Variant Quantity
7SJ610*– 3 (configurable)
7SJ611*– 8 (configurable)
7SJ612*– 11 (configurable)
7SJ613*– 8 (configurable)
7SJ614*– 11 (configurable)
Rated Voltage Range DC 24 V to 250 V, bipolar
Current Consumption (independent of the control
voltage)
approx. 1.8 mA
Pickup time approx. 4 ms
Switching Thresholds Switching Thresholds, adjustable voltage range with
jumpers
For Nominal Voltages DC 24 V/ 48 V/ 60 V/ 110 V/ 125 V V high≥ DC 19 V
V low ≤ DC 10 V
For Nominal Voltages DC 110 V/ 125 V/ 220 V/ 250 V V high ≥ DC 88 V
V low ≤ DC 44V
for nominal voltages (only for modules with 3
switching thresholds)
DC 220 V/ 250 V and AC 115 V/
230 V
V high ≤ DC 176 V
V low ≤ DC 88 V
Maximum admissible voltage DC 300 V
Impulse Filter on Input 220 nF Coupling Capacitor at 220 V with recovery time
> 60 ms
Output Relays
Output Relay for Commands/Annunciations, Alarm Relay
*
)
Number and Information According to the Order Variant (allocatable);
Values in ( ): up to release .../DD
Order variant Schließer S/Ö, umschaltbar
7SJ610*– 2 (4) 3 (1)
7SJ611*– 6 (8) 3 (1)
7SJ612*– 4 (6) 3 (1)
7SJ613*– 6 (8) 3 (1)
7SJ614*– 4 (6) 3 (1)
Switching capability CLOSE 1000 W/VA
Switching capability TRIP 30 VA 40 W resistive 25 W
bei L/R ≤ 50 ms
Switching voltage DC 250 V/ AC 250 V
Admissible current per contact (continuous) 5 A
Admissible current per contact (close and hold) 30 A for 0.5 s (NO contact)
Total Current on common path 5 A continuous, 30 A for 0.5 s
4.1.3
Technical Data
4.1 General Device Data
SIPROTEC 4, 7SJ61, Manual 281
C53000-G1140-C210-6, Edition 05.2016
