Siemens SIPROTEC 4 7SJ61 User Manual

Electrical Tests
Regulations
Standards: IEC 60255 (product standards)
ANSI/IEEE Std C37.90.0/.1/.2
UL 508
DIN 57435 Part 303
for more standards see also individual functions
Insulation Test
Standards: IEC 60255-5 and IEC 60870-2-1
High Voltage Test (routine test) All circuits except
power supply, Binary Inputs, Communication Inter-
face and Time Synchronization Interfaces
2.5 kV (rms), 50 Hz
High voltage test (routine test). Auxiliary voltage
and binary inputs
3.5 kV–
High Voltage Test (routine test). Only Isolated
Communication and Time Synchronization Inter-
faces
500 V (rms), 50 Hz
Impulse Voltage Test (type test). All Circuits Except
Communication and Time Synchronization Inter-
faces, Class III
5 kV (peak value); 1.2/50 μs; 0.5 J;
3 positive and 3 negative impulses at intervals of 1 s
EMC Tests for Immunity (Type Tests)
Standards:
IEC 60255-6 and -22, (product standards)
EN 50082-2 (generic standard)
DIN 57435 Part 303
High frequency test IEC 60255-22-1,
Class III and VDE 0435 Part 303, Class III
2.5 kV (Peak); 1 MHz; τ = 15 μs; 400 Surges
per s; Test duration 2 s; R
i
= 200 Ω
Electrostatic discharge IEC 60255-22-2,
Class IV and IEC 61000-4-2, Class IV
8 kV contact discharge; 15 kV air discharge,
both polarities; R
i
= 330 Ω
Exposure to HF field, non-modulated
IEC 60255-22-3 (report), Class III
10 V/m; 27 MHz to 500 MHz
Irradiation with HF field, amplitude modulated
IEC 61000-4-3, Class III
10 V/m; 80 MHz to 1000 MHz; 80 % AM;
1 kHz
Irradiation with HF field, pulse modulated
IEC 61000-4-3/ENV 50204, Class III
10 V/m; 900 MHz; repetition frequency 200
Hz; duty cycle of 50 %
Fast transient disturbance variables / burst
IEC 60255-22-4 and IEC 61000-4-4, Class IV
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms;
repetition rate 300 ms; both polarities; R
i
=
50 Ω; test duration 1 min
High energy surge voltages (SURGE),
IEC 61000-4-5 Installation Class 3
Impulse: 1.2/50 μ
Auxiliary voltage common mode: 2 kV; 12 Ω; 9 μF
diff. mode:1 kV; 2 Ω; 18 μF
Measuring inputs, binary inputs and
relay outputs
common mode: 2 kV; 42 Ω; 0,5 µF
diff. mode: 1 kV; 42 Ω; 0,5 µF
HF on lines, amplitude-modulated
IEC 61000-4-6, Class III
10 V; 150 kHz to 80 MHz; 80 % AM; 1 kHz
4.1.5
Technical Data
4.1 General Device Data
286 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
