Information List
No. Information Type of
Informa-
tion
Comments
- I Admd> LV I A dmd>
- I Bdmd> LV I B dmd>
- I Cdmd> LV I C dmd>
- I1dmd> LV I1dmd>
- 37-1 LV 37-1 under current
273 SP. I A dmd> OUT Set Point Phase A dmd>
274 SP. I B dmd> OUT Set Point Phase B dmd>
275 SP. I C dmd> OUT Set Point Phase C dmd>
276 SP. I1dmd> OUT Set Point positive sequence I1dmd>
284 SP. 37-1 alarm OUT Set Point 37-1 Undercurrent alarm
Set Points for Statistic
Description
For the statistical counters, setpoints may be entered and a message is generated as soon as they are reached.
The message can be allocated to both output relays and LEDs.
Setting Notes
Setpoints for the Statistical Counter
The setting of threshold values for the statistical counters takes place in DIGSI under Messages → Statistics in
the sub-menu Threshold Values for Statistics. Double-click to display the corresponding contents in another
window. By overwriting the previous value the settings can be changed (please refer to the SIPROTEC 4
System Description).
Information List
No.
Information Type of
Informa-
tion
Comments
- OpHour> LV Operating hours greater than
272 SP. Op Hours> OUT Set Point Operating Hours
16004 ΣI^x> LV Threshold Sum Current Exponentiation
16005 Threshold ΣI^x> OUT Threshold Sum Curr. Exponent. exceeded
16009 Resid.Endu. < LV Lower Threshold of CB Residual Endurance
16010 Thresh.R.Endu.< OUT Dropped below Threshold CB Res.Endurance
16017 ΣI^2t> LV Threshold Sum Squared Current Integral
16018 Thresh. ΣI^2t> OUT Threshold Sum Squa. Curr. Int. exceeded
Commissioning Aids
Device data sent to a central or master computer system during test mode or commissioning can be influ-
enced. There are tools for testing the system interface and the binary inputs and outputs of the device.
