device data via parameter 640 Start image DD. The available image pages are listed in E Default Settings
and Protocol-dependent Functions.
IEC60870-5-103 Measured Value Telegrams
Via parameter T103 with 16 MV, address 617, the scope of measured values to be transmitted to a master
can be influenced.
Normally (setting = NO) the maximum scope of measured values is transmitted using several measured value
telegrams.
If set to YES, the transmission is restricted to one measured value telegram containing 16 measured values.
This setting (YES) is used to create a status that is compatible with a legacy Siemens LSA.
IEC 61850 GOOSE Function
At address 700 GOOSE-Stop you can set the GOOSE function of the IEC 61850 protocol to active or not. If
GOOSE-Stop is set to YES, you can release the GOOSE function again via a binary input during operation.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
Addr. Parameter Setting Options Default Setting Comments
610 FltDisp.LED/LCD Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
617A T103 with 16 MV YES
NO
OFF
NO T103-transfer limeted to 16 meas.
values
625A T MIN LED HOLD 0 .. 60 min; ∞ 0 min Minimum hold time of latched
LEDs
640 Start image DD image 1
image 2
image 7
image 8
image 9
image 10
image 1 Start image Default Display
700 GOOSE-Stop YES
NO
NO GOOSE-Stop
Information List
No.
Information Type of
Informa-
tion
Comments
- >Light on SP >Back Light on
- Reset LED IntSP Reset LED
- DataStop IntSP Stop data transmission
- Test mode IntSP Test mode
- Feeder gnd IntSP Feeder GROUNDED
- Brk OPENED IntSP Breaker OPENED
- HWTestMod IntSP Hardware Test Mode
- SynchClock IntSP_Ev Clock Synchronization
- Error FMS1 OUT Error FMS FO 1
- Error FMS2 OUT Error FMS FO 2
- Distur.CFC OUT Disturbance CFC
2.1.2.3
2.1.2.4
Functions
2.1 General
SIPROTEC 4, 7SJ61, Manual 33
C53000-G1140-C210-6, Edition 05.2016
