Addr. Parameter C Setting Options Default Setting Comments
4008 46-TOC PICKUP 1A 0.05 .. 2.00 A 0.90 A 46-TOC Pickup
5A 0.25 .. 10.00 A 4.50 A
4009 46-TOC TIMEDIAL 0.50 .. 15.00 ; ∞ 5.00 46-TOC Time Dial
4010 46-TOC TIMEDIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 46-TOC Time Dial
4011 46-TOC RESET Instantaneous
Disk Emulation
Instantaneous 46-TOC Drop Out
4012A 46 T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 46 Drop-Out Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
5143 >BLOCK 46 SP >BLOCK 46
5151 46 OFF OUT 46 switched OFF
5152 46 BLOCKED OUT 46 is BLOCKED
5153 46 ACTIVE OUT 46 is ACTIVE
5159 46-2 picked up OUT 46-2 picked up
5165 46-1 picked up OUT 46-1 picked up
5166 46-TOC pickedup OUT 46-TOC picked up
5170 46 TRIP OUT 46 TRIP
5171 46 Dsk pickedup OUT 46 Disk emulation picked up
2.5.5
Functions
2.5 Negative Sequence Protection 46
SIPROTEC 4, 7SJ61, Manual 93
C53000-G1140-C210-6, Edition 05.2016
