Measured Values
No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- I A dmd> (I Admd>) Set Points(MV) - - - - - CFC CD DD
- I B dmd> (I Bdmd>) Set Points(MV) - - - - - CFC CD DD
- I C dmd> (I Cdmd>) Set Points(MV) - - - - - CFC CD DD
- I1dmd> (I1dmd>) Set Points(MV) - - - - - CFC CD DD
- 37-1 under current (37-1) Set Points(MV) - - - - - CFC CD DD
- Number of TRIPs= (#of TRIPs=) Statistics - - - - - CFC CD DD
- Operating hours greater than
(OpHour>)
SetPoint(Stat) - - - - - CFC CD DD
601 Ia (Ia =) Measurement 134 137 No 9 1 CFC CD DD
602 Ib (Ib =) Measurement 160 145 Yes 3 1 CFC CD DD
134 137 No 9 2
603 Ic (Ic =) Measurement 134 137 No 9 3 CFC CD DD
604 In (In =) Measurement 134 137 No 9 4 CFC CD DD
605 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
606 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ
REST. =)
Measurement - - - - - CFC CD DD
805 Temperature of Rotor (ΘR/
ΘRtrip=)
Measurement - - - - - CFC CD DD
807 Thermal Overload (Θ/Θtrip =) Measurement - - - - - CFC CD DD
809 Time untill release of reclose-
blocking (T reclose=)
Measurement - - - - - CFC CD DD
830 INs Senstive Ground Fault Current
(INs =)
Measurement 134 118 No 9 3 CFC CD DD
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC CD DD
833 I1 (positive sequence) Demand (I1
dmd=)
Demand meter - - - - - CFC CD DD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CD DD
838 I A Demand Maximum
(IAdmdMax)
Min/Max meter - - - - - CD DD
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CD DD
840 I B Demand Maximum
(IBdmdMax)
Min/Max meter - - - - - CD DD
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CD DD
842 I C Demand Maximum
(ICdmdMax)
Min/Max meter - - - - - CD DD
843 I1 (positive sequence) Demand
Minimum (I1dmdMin)
Min/Max meter - - - - - CD DD
F.5
Functions, Settings, Information
F.5 Measured Values
438 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
