No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
844 I1 (positive sequence) Demand
Maximum (I1dmdMax)
Min/Max meter - - - - - CD DD
851 Ia Min (Ia Min=) Min/Max meter - - - - - CD DD
852 Ia Max (Ia Max=) Min/Max meter - - - - - CD DD
853 Ib Min (Ib Min=) Min/Max meter - - - - - CD DD
854 Ib Max (Ib Max=) Min/Max meter - - - - - CD DD
855 Ic Min (Ic Min=) Min/Max meter - - - - - CD DD
856 Ic Max (Ic Max=) Min/Max meter - - - - - CD DD
857 I1 (positive sequence) Minimum
(I1 Min=)
Min/Max meter - - - - - CD DD
858 I1 (positive sequence) Maximum
(I1 Max=)
Min/Max meter - - - - - CD DD
888 Pulsed Energy Wp (active)
(Wp(puls))
Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive)
(Wq(puls))
Energy 133 56 No 205 - CFC CD DD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD DD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD DD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD DD
1058 Overload Meter Max (Θ/
ΘTrpMax=)
Min/Max meter - - - - - CD DD
1059 Overload Meter Min (Θ/ΘTrpMin=) Min/Max meter - - - - - CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Measurement 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Measurement 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Measurement 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Measurement 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Measurement 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Measurement 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Measurement 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Measurement 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Measurement 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10
=)
Measurement 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11
=)
Measurement 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12
=)
Measurement 134 146 No 9 12 CFC CD DD
16004 Threshold Sum Current Exponen-
tiation (ΣI^x>)
SetPoint(Stat) - - - - - CFC CD DD
16009 Lower Threshold of CB Residual
Endurance (Resid.Endu. <)
SetPoint(Stat) - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SJ61, Manual 439
C53000-G1140-C210-6, Edition 05.2016
