Average Measurements
The long-term averages are calculated and output by the 7SJ61.
Description
Long-Term Averages
The long-term averages of the three phase currents Ι
x
, and the positive sequence components Ι
1
for the three
phase currents are calculated within a set period of time and indicated in primary values.
For the long-term average values mentioned above, the length of the time window for averaging and the
frequency with which it is updated can be set.
Setting Notes
Average Calculation
The selection of the time period for measured value averaging is set with parameter 8301 DMD Interval in
the corresponding setting group from A to D under MEASUREMENT. The first number specifies the averaging
time window in minutes while the second number gives the frequency of updates within the time window. 15
Min., 3 Subs, for example, means: Time average is generated for all measured values with a window of 15
minutes. The output is updated every 15/3 = 5 minutes.
With address 8302 DMD Sync.Time, the starting time for the averaging window set under address 8301 is
determined. This setting specifies if the window should start on the hour (On The Hour) or 15 minutes later
(15 After Hour) or 30 minutes / 45 minutes after the hour (30 After Hour oder 45 After Hour).
If the settings for averaging are changed, then the measured values stored in the buffer are deleted, and new
results for the average calculation are only available after the set time period has passed.
Settings
Addr.
Parameter Setting Options Default Setting Comments
8301 DMD Interval 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
8302 DMD Sync.Time On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
Information List
No.
Information Type of
Informa-
tion
Comments
833 I1 dmd= MV I1 (positive sequence) Demand
963 Ia dmd= MV I A demand
964 Ib dmd= MV I B demand
965 Ic dmd= MV I C demand
2.17.4
2.17.4.1
2.17.4.2
2.17.4.3
2.17.4.4
Functions
2.17 Auxiliary Functions
208 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
