Siemens SIPROTEC 4 7SJ61 User Manual

Binary Input
Table E-2 Binary input presettings for all devices and ordering variants
Binary Input Default function Function No. Description
BI1 >BLOCK 50-2 1721 >BLOCK 50-2
>BLOCK 50N-2 1724 >BLOCK 50N-2
BI2 >Reset LED 5 >Reset LED
BI3 >Light on >Back Light on
Table E-3 Further binary input presettings for 7SJ611*-, 7SJ612*-, 7SJ613*- und 7SJ614*-
Binary Input Default function Function No. Description
BI4 >52-b 4602 >52-b contact (OPEN, if bkr is closed)
52Breaker 52 Breaker
BI5 >52-a 4601 >52-a contact (OPEN, if bkr is open)
52Breaker 52 Breaker
E.2
Default Settings and Protocol-dependent Functions
E.2 Binary Input
SIPROTEC 4, 7SJ61, Manual 375
C53000-G1140-C210-6, Edition 05.2016
