Ordering Information 7SJ61 V4.9
Multi-Functional
Protection with
Control
6 7 8 9 10 11 12 13 14 15 16 Zusatz
7 S J 6 1 – – +
Number of Binary Inputs and Outputs Pos. 6
Housing
1
/
3
19”, 4-line Display, 3 BI, 4 BO, 1 Live Contact
0
Housing
1
/
3
19”, 4-line Display, 8 BI, 8 BO, 1 Live Contact
1
Housing
1
/
3
19”, 4-line Display, 11 BI, 6 BO, 1 Live Contact
2
Housing
1
/
2
19”, Graphic Display, 8 BI, 8 BO, 1 Live Contact
3
Housing
1
/
2
19”, Graphic Display, 11 BI, 6 BO, 1 Live Contact
4
Nominal current Pos. 7
Ι
ph
= 1 A, Ι
N
= 1 A (min. = 0.05 A); 15th position only with A
1
Ι
ph
= 1 A, Ι
N
= sensitive (min. = 0.001 A); 15th position only with B
2
Ι
ph
= 5 A, Ι
N
= 5 A (min. = 0.25 A); 15th position only with A
5
Ι
ph
= 5 A, Ι
N
= sensitive (min. = 0.001 A); 15th position only with B
6
Ι
ph
= 5 A, Ι
e
= 1 A (min. = 0.05 A); 15th position only with A
7
Auxiliary Voltage (Power Supply, Pickup Threshold of Binary Inputs) Pos. 8
DC 24 to 48 V, Binary Input Threshold DC 19 V 2
DC 60 to 125 V, Binary Input Threshold DC 19 V 4
DC 110 to 250 V, AC 115 V to 230 V, Binary Input Threshold DC 88 V 5
DC 110 to 250 V, AC 115 V to 230 V, Binary Input Threshold DC 176 V 6
Construction Pos. 9
Surface-mounting case for panel, 2 tier terminals top/bottom B
Flush mounting case, plug-in terminals (2/3-pole connector) D
Flush mounting case, screw-type terminals (direct connection / ring lugs) E
Region-specific default / language settings and function versions Pos. 10
Region DE, 50 Hz, IEC, German Language (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, Language English (Language can be changed) B
Region US, 60/50 Hz, ANSI, Language American English (Language can be changed) C
Region FR, 50/60 Hz, IEC/ANSI, Language French (Language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, Language Spanish (Language can be changed) E
Region World, 50/60 Hz, IEC/ANSI, Language Italian (Language selectable) F
Region World, 50/60 Hz, IEC/ANSI, Language Russian (Language selectable) G
System Interface (Rear Side, Port B) Pos. 11
No system interface 0
IEC-Protocol, electrical RS232 1
IEC-Protocol, electrical RS485 2
IEC Protocol, Optical, 820 nm, ST Connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, Optical, Single Ring, ST-Connector
1)
5
1)
Profibus FMS Slave, Optical, Double Ring, ST-Connector
1)
6
1)
For further interface options see Additional Information in the following 9
A.1
Ordering Information and Accessories
A.1 Ordering Information 7SJ61 V4.9
346 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
