Addr. Parameter C Setting Options Default Setting Comments
4211 TEMPSENSOR RTD 1 .. 6 1 Temperature sensor
connected to RTD
4212 TEMPSENSOR RTD 1 .. 12 1 Temperature sensor
connected to RTD
Information List
No. Information Type of
Informa-
tion
Comments
1503 >BLOCK 49 O/L SP >BLOCK 49 Overload Protection
1507 >EmergencyStart SP >Emergency start of motors
1511 49 O / L OFF OUT 49 Overload Protection is OFF
1512 49 O/L BLOCK OUT 49 Overload Protection is BLOCKED
1513 49 O/L ACTIVE OUT 49 Overload Protection is ACTIVE
1515 49 O/L I Alarm OUT 49 Overload Current Alarm (I alarm)
1516 49 O/L Θ Alarm OUT 49 Overload Alarm! Near Thermal Trip
1517 49 Winding O/L OUT 49 Winding Overload
1521 49 Th O/L TRIP OUT 49 Thermal Overload TRIP
1580 >RES 49 Image SP >49 Reset of Thermal Overload Image
1581 49 Image res. OUT 49 Thermal Overload Image reset
2.7.4
Functions
2.7 Thermal Overload Protection 49
120 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
