Siemens SIPROTEC 4 7SJ61 User Manual

Binary Output
Table E-4 Output Relay Presettings for All Devices and Ordering Variants
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO3 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO4 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
Table E-5 Further Output Relay Presettings for 7SJ611**-, 7SJ612**-, 7SJ613**-, 7SJ614**-
Binary Output Default function Function No. Description
BO7 Relay PICKUP 501 Relay PICKUP
E.3
Default Settings and Protocol-dependent Functions
E.3 Binary Output
376 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
