Addr. Parameter C Setting Options Default Setting Comments
214 Rated Frequency 50 Hz
60 Hz
50 Hz Rated Frequency
217 Ignd-CT PRIM 1 .. 50000 A 60 A Ignd-CT rated primary
current
218 Ignd-CT SEC 1A
5A
1A Ignd-CT rated secondary
current
235A ATEX100 NO
YES
NO Storage of th. Replicas w/o
Power Supply
238 Ignd2-CT PRIM 1 .. 50000 A 60 A Ignd2-CT rated primary c.
(conn. to I2)
250A 50/51 2-ph prot ON
OFF
OFF 50, 51 Time Overcurrent
with 2ph. prot.
251A CT Connect. A, B, C, (Gnd)
A,G2,C,G; G->B
A,G2,C,G; G2->B
A, B, C, (Gnd) CT Connection
260 Ir-52 10 .. 50000 A 125 A Rated Normal Current (52
Breaker)
261 OP.CYCLES AT Ir 100 .. 1000000 10000 Switching Cycles at Rated
Normal Current
262 Isc-52 10 .. 100000 A 25000 A Rated Short-Circuit
Breaking Current
263 OP.CYCLES Isc 1 .. 1000 50 Switch. Cycles at Rated
Short-Cir. Curr.
264 Ix EXPONENT 1.0 .. 3.0 2.0 Exponent for the Ix-
Method
265 Cmd.via control (Einstellmöglichkeiten
anwendungsabhängig)
none 52 B.Wear: Open Cmd. via
Control Device
266 T 52 BREAKTIME 1 .. 600 ms 80 ms Breaktime (52 Breaker)
267 T 52 OPENING 1 .. 500 ms 65 ms Opening Time (52 Breaker)
276 TEMP. UNIT Celsius
Fahrenheit
Celsius Unit of temperature meas-
urement
280 Holmgr. for Σi NO
YES
NO Holmgreen-conn. (for fast
sum-i-monit.)
281A Swi.auth.via BI NO
YES
OFF
NO Change switch.authority
via binary input
282A Interl.on/offBI NO
YES
OFF
NO Interlocking on or off via
binary input
613A 50N/51N/67N w. Ignd (measured)
3I0 (calcul.)
Ignd (measured) 50N/51N/67N Ground
Overcurrent with
Information List
No.
Information Type of
Informa-
tion
Comments
5145 >Reverse Rot. SP >Reverse Phase Rotation
5147 Rotation ABC OUT Phase rotation ABC
5148 Rotation ACB OUT Phase rotation ACB
2.1.3.4
Functions
2.1 General
40 SIPROTEC 4, 7SJ61, Manual
C53000-G1140-C210-6, Edition 05.2016
