5.5.1.5 Display of the operating state
You can nd additional information on this under "Advanced" in the Chapter Function
description (Page 68).
5.5.1.6 Function setting
DIP switch settings
You can nd additional information on this under "Advanced" in the Chapter Functions
(Page 69).
State diagrams 3SK1220
Signal to
Basic unit
3SK1220 Autostart
InputsOutputs
IN1/IN2 (sensor
circuit)
30 ms
80 ms
3SK1 / 3RQ1 devices
5.5 3SK1 input expansions
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
106 Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005
