5.1.4 3SK1112 Standard basic unit instantaneous (with semiconductor outputs)
5.1.4.1 General information
Article number
3SK1112-xBB40 24 V DC
x = 1: Screw-type terminal; x = 2: Spring-loaded (push-in) terminal
Device features
• 4-way DIP switch for function setting (parameterization)
• SET/RESET button
• 4 LEDs for status and function display
• 2 sensor inputs (channels 1 and 2)
• 1 input (cascading circuit)
• 1 input (START pushbutton circuit)
• 1 input (feedback circuit)
• 2 test outputs
• 2 safety-related semiconductor outputs
• 1 semiconductor signaling circuit
• Enclosure width 22.5 mm
• Removable terminals
WARNING
Continuous operation
Devices up to E01/V1.0.0:
In continuous operation for PL e/Cat. 4 in accordance with ISO 13849-1 or SILCL 3 in accordance
with IEC 62061, the key safety values apply where the function test interval (state change of
the outputs) ≤ 1 year.
Devices from E02/V1.1.0:
In continuous operation for PL e/Cat. 4 in accordance with ISO 13849-1 or SILCL 3 in accordance
with IEC 62061, the key safety values apply where the function test interval (state change of
the outputs) ≤ 20 years.
3SK1 / 3RQ1 devices
5.1 3SK1 standard
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
60 Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005
