8.2.8 Connection data for 3RQ1 spring-loaded terminal (push-in system)
Connection data for ... Control current terminals
Connectable conductor cross-sections for solid cables 1 x (0.5 .. 4.0) mm²
(AWG
1)
: 1 x 20 to 12)
Connectable conductor cross-sections for
exible cables
Without end sleeve 1 x (0.5 ... 4.0) mm²
(AWG
1)
: 1 x 20 to 12)
With end sleeve (with and without
plastic sleeve)
1 x (0.5 ... 2.5) mm²
(AWG
1)
: 1 x 20 to 12)
Cable stripping length 10 mm
End sleeves according to DIN 46228‑4 with plastic sleeve 10 mm
1)
AWG: American Wire Gauge (AWG does not dene use of end sleeves)
8.2.9 Connecting spring-loaded (push-in) terminals
WARNING
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
The spring-loaded (push-in) system allows wiring without tools for rigid conductors or
conductors equipped with end sleeves.
A screwdriver is required for wiring nely-stranded or stranded conductors without end sleeves
on spring-loaded (push-in) terminals.
Tools and materials
• 0.5 x 3 mm screwdriver DIN 5264 (for nely-stranded conductors only).
• For suitable connection cross-sections of the cables, see the chapter "Connection data for
3SK1 terminals (Page 157)".
Connection
8.2 22.5 mm/17.5 mm devices
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005 161
