7.4 Disassembling devices from a level surface
WARNING
Hazardous voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
• The terminals have been removed or disconnected.
Procedure
Figure 7-5 Disassembling 17.5 mm and 22.5 mm devices
Mounting
7.4 Disassembling devices from a level surface
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005 127
