7.7 Removing devices from a standard mounting rail
WARNING
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
• The terminals have been removed or disconnected.
Procedure
1. Press the device downwards.
2. Pull the lower half of the device away from the standard mounting rail.
3. Lift the device from the upper edge of the standard mounting rail.
Mounting
7.7 Removing devices from a standard mounting rail
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005 131
