3. Hold the cable in the spring-loaded terminal.
4. Remove the screwdriver.
5. Pull on the cable to ensure it is tight.
8.3.4 Mounting terminals
WARNING
Hazardous voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
You must have removed the terminals, for the purpose of replacing a device, for example.
Procedure for mounting terminals


1. Insert the detachable terminals into the guide rail of the device.
2. Slide the detachable terminals back until they audibly engage.
3. Check that the clip of the removable terminals closes 󹪞ush with the front panel.
Connection
8.3 Devices 90 mm
SIRIUS 3SK1 Safety Relays and 3RQ1 Positively-Driven Coupling Relays
170 Equipment Manual, 05/2021, A5E02526190021A/RS-AE/005
