Siemens SIROTEC Equipment Manual

Line Connection Booksize
2.10 Line reactors for Active Line Modules
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
103
Figure 2-36 Dimension drawing: line reactor for Active Line Modules (as of 80 kW)
Table 2-34 Dimensions of the line reactor for Active Line Modules
Order
number
L [mm]
(inches)
W [mm]
(inches)
h1 [mm]
(inches)
h2 [mm]
(inches)
H [mm]
(inches)
w [mm]
(inches)
n
1
[mm]
1)
(inches)
n
2
[mm]
1)
(inches)
n
3
[mm]
1)
(inches)
80 kW 6SN1111-
0AA00-
1EAx
380
(14.96)
225
(8.86)
50 (1.70) 170
(6.69)
220
(8.66)
170
(6.69)
175 (6.89) 325
(12.80)
156
(6.14)
120 kW 6SL3000-
0DE31-
2BAx
476
(18.74)
275
(10.82)
80 (3.14) 215
(8.46)
265
(10.43)
230
(9.05)
175 (6.89) 325
(12.80)
206
(8.11)
1) Dimensions n1, n2 and n3 correspond to the hole spacing
2.10.5 Technical data
Table 2-35 Technical data of line reactors for the Active Line Module
Unit
6SN1111–0AA00-
0BA1
6SN1111–0AA00-
0CA1
6SN1111–0AA00-
0DA1
6SN1111–0AA00-
1EAx
6SL3000-0DE31-
2BAx
Power kW 16 36 55 80 120
Rated current A
rms
30 67 103 150 225
Power loss
1)
W 170 250 350 450 590
Weight [kg] 8.5 13 18 40 64
1)
For an overview, see the power loss tables in chapter Cabinet Design
