Siemens SIROTEC Equipment Manual

Line Connection Booksize
2.9 Active Interface Modules internal air cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
99
2.9.6 Technical data
Table 2-30 Technical data
Active Interface Module 6SL3100- 0BE21-6ABO 0BE23-6ABO
16 kW 36 kW
P
max
kW 35 70
I
rated
A 27 60
I
max
A 59 117
Current requirements of the 24 V
DC electronics power supply
mA 250 490
Line voltage V 380 V 3 AC to 480 V 3 AC ±10%
Line frequency Hz 47 - 63
Cooling air requirement m
3
/h 112 160
Power loss W 135 + 255 = 390 135 + 360 = 495
Weight kg 10.7 18.5
Connection cross-section mm
2
10 35
PE connecting studs M5 M5
Table 2-31 Technical data
Active Interface Module 6SL3100- 0BE25-5ABx 0BE28-0ABx 0BE31-2ABx
55 kW 80 kW 120 kW
P
max
kW 110 131 175
I
rated
A 88 132 200
I
max
A 176 218 292
Current requirements of the 24 V
DC electronics power supply
A 1.2 1.2 1.2
Line voltage V 380 V to 480 V 3 AC ±10%
Line frequency Hz 47 - 63
Cooling air requirement m
3
/h 300 600 600
Power loss W 450 575 800
Weight kg 21 29 35.5
Connection cross-section mm
2
50 120 120
PE connecting studs M6 M8 M8
