Siemens SIROTEC Equipment Manual

Cabinet Design and EMC Booksize
9.7 Cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
535
9.7 9.7 Cooling
9.7.1 General
The cabinet can be cooled, among others, by using:
● filtered fans
● heat exchangers or
● cooling units.
The decision in favor of one of these methods will depend on the prevailing ambient
conditions and the cooling power required.
The air routing inside the control cabinet and the cooling clearances specified here, must be
carefully observed. No other components or cables must be located in these areas.
CAUTION
If you do not observe the guidelines for installing SINAMICS equipment in the cabinet, this
can reduce the service life of the equipment and result in premature component failure.
You must take into account the following specifications when installing a SINAMICS drive
line-up:
● Ventilation clearance
● Wiring and cabling
● Air guidance, air-conditioner
Table 9-20 Ventilation clearances above and below the components
Component Order number Clearance [mm]
CU320 6SL3040-0MA00-0AAx 80
SMCxx 6SL3055-0AA00-5xAx 50
TM15 6SL3055-0AA00-3FAx 50
TM31 6SL3055-0AA00-3AAx 50
TM41 6SL3055-0AA00-3PAx 50
Line filter for line module
5 kW - 120 kW 6SL3000-0BExx-xAAx 100
Active Interface Module
50 kW
80 kW
120 kW
6SL3100-0BE25-5ABx
6SL3100-0BE28-0ABx
6SL3100-0BE31-2ABx
80
Line reactor for active line module
16 kW – 120 kW 6SN1111-0AA00-xxAx 100
Line reactor for Basic Line Module
20 kW – 100 kW 6SL3000-0CExx-0AAx 100
