Line Modules Booksize
3.4 Basic Line Modules with internal air cooling
Booksize power units
218 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
3.4.5 Mounting
Basic Line Modules are installed in the same way as Active Line Modules and Booksize
Motor Modules.
The Basic Line Modules are designed for installation in the control cabinet. The
components are secured onto the control cabinet installation panel using M6 screws.
0
1P
7RU[7
Figure 3-42 Mounting: Basic Line Module 100 kW
