Cabinet Design and EMC Booksize
9.6 Connection systems
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
529
9.6.3 Motor connector
8
:
9
Figure 9-10 Motor connector
The figure below shows how to remove the motor connector using a pair of engineer's pliers,
for example, to pull the cable through narrow cable bushings.
Figure 9-11 Removing the motor connector
