Line Connection Booksize
2.7 Basic Line Filter for Basic Line Modules
Booksize power units
68 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
2.7.3.2 Line/power connection
Table 2-12 Connection type
Terminals Designations
Line supply connection (line supply) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Basic Line Filter for Basic Line Modules
20 kW Screw terminal: 10 mm
2
3-pin/1.5 - 1.8 Nm (see Screw Terminals chapter)
PE connection: M6/6 Nm
1)
40 kW Screw terminal: 35 mm
2
PE connection: M6/6 Nm
1)
100 kW Screw terminal: 95 mm
2
PE connection: M6/6 Nm
1)
1) for ring cable lugs to DIN 46234
