Siemens SIROTEC Equipment Manual

Line Modules Booksize
3.3 Active Line Modules with external air cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
183
3.3.3.7 Meaning of the LEDs on the Active Line Module
Table 3-17 Active Line Module - description of the LEDs
Status Description, cause Remedy
Ready (H200) DC link (H201)
off off Electronics power supply is missing or outside
permissible tolerance range.
–
off The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
–
Orange The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is present.
–
Green
Red The component is ready for operation and cyclic
DRIVE-CLiQ communication is taking place.
The DC link voltage is too high.
Check line voltage
Orange Orange DRIVE-CLiQ communication is being established. –
Red – At least one fault is present in this component.
Note:
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Remedy and acknowledge
fault
Green/red
(0.5 Hz)
- Firmware is being downloaded. –
Green/red
(2 Hz)
- Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green/orange
or
Red/orange
– Component detection via LED is activated (p0124).
Note:
Both options depend on the LED status when
component recognition is activated via p0124 = 1.
–
DANGER
Hazardous DC link voltages may be present at any time regardless of the status of the
"DC link" LED.
The warning information on the components must be carefully observed!
