Accessories
8.3 DC link adapter
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
473
8.3.3.2 DC link connection
Table 8-13 DC link adapter – description of the terminals
Terminal Function Technical specifications
DCP DC link positive
DCN DC link negative
Two-row configuration of adapter 35 – 95 mm²
Current carrying capacity: 200 A
Voltage: 720 V-VDE/600 V AC
Connection cross-section: 35 – 95 mm²
Stripped length: 27 mm
