9.6 Connection systems
Booksize power units
526 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
9.6.2 Connectable cable cross-sections
Table 9-15 Connectable cable cross-sections: Power supply cable/motor cable, part 1
Connection cross-section [mm
2
]
Component Terminal type 1.5 2.5 4 6 10 16
Motor Module Booksize format
3 A to 30 A
2 x 3 A to 2 x 18 A
Motor connector 30 A 3+2 pin X X X X X
Motor Module Booksize Compact
format
1.7 A - 18 A
Screw terminal X X X X
Motor Module
45 A to 60 A
Threaded bolt M6/6 Nm
1)
X X X X X
Motor Module 85 A Threaded bolt M8/13 Nm X X X X X
Motor Module
132 A to 200 A
Threaded bolt M8/13 Nm X X X X X
Smart Line Module Booksize
format
5 kW to 10 kW
Screw terminal X X X X
Smart Line Module Booksize
Compact format
16 kW
Screw terminal X X X X X X
Acitve Line Module 16 kW
Smart Line Module 16 kW
Screw terminal X X X X X
Acitve Line Module 36 kW
Smart Line Module 36 kW
Threaded bolt M6/6 Nm X X X X X
Acitve Line Module 55 kW Threaded bolt M8/13 Nm X X X X X
Active Line Module
80 kW to 120 kW
Threaded bolt M8/13 Nm X X X X X
1)
for ring cable lugs to DIN 46234
Terminal area for flexible cable with wire end ferrule
Terminal area for flexible cable with ring cable lug M6
Terminal area for flexible cable with ring cable lug M8
IP2xB to EN 60529 ensured; note: the shock-hazard protection installed as standard must be used or adjusted as appropriate.
