Accessories
8.1 Shield connecting plates
Booksize power units
454 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
8.1.4 Installation
Table 8-1 Mounting the shield connecting plate to a 100 mm component using as an example, internal air cooling
Remove the screw with
screwdriver T25
Hook in the shielded plate. Secure the shield connecting
plate with screwdriver
T25/3 Nm
Mounted shield connecting
plate
