Line Connection Booksize
2.7 Basic Line Filter for Basic Line Modules
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
71
2.7.5 Technical data
Table 2-15 Technical data for Basic Line Filter for Basic Line Modules
6SL3000
unit
0BE21-6DAx 0BE23-6DA1 0BE31-2DAx
Rated power kW 20 40 100
Connection voltage:
Supply voltage
Line frequency
V
AC
Hz
380 3 AC -10% (-15% < 1 min) to 480 3 AC +10%
47 to 63 Hz
Rated current A
AC
36 65 192
Power loss
1)
W 16 28 86
Weight kg 5 6.5 18.5
1)
For an overview, see the power loss tables in chapter Cabinet Design
